TCA称重传感器详细信息请点击:英国LCMsystems称重传感器获取最新报价!!!
产品品牌:英国LCMsystems(LOADCELL)
产品类别:不锈钢拉压式双向受力
产品系列:LCM拉压力TCA系列称重传感器
产品型号:TCA-1T,TCA-2T,TCA-3T,TCA-5T,TCA-7.5T,TCA-10T,TCA-20T,TCA-30T,TCA-50T,TCA-75T,TCA-100T
英国LCMsystems TCA称重传感器特点
▲范围从1tonne到100tonne
▲不锈钢结构。
▲环境密封等级为IP66(IP67和潜水的版本也可提供)
▲设计,以适应标准公制杆端轴承的尺寸。
▲特殊尺寸和可用范围。
▲可以提供英制和公制螺纹。
▲可提供完整的交配球形杆端轴承。
产品描述:该TCA系列称重传感器是非常适合测量拉伸和压缩力。在称重传感器各端标准公制螺纹的目的是接受标准的球形座杆端轴承。有很大的灵活性,在TCA的设计,使我们能够提供特殊尺寸,以满足特定的应用需求,或不同的端螺纹尺寸/组合。有可与外螺纹的每一端的版本,或外螺纹的一端,雌性另一个。
英国LCMsystems TCA称重传感器技术指标
Rated Load (tonne)
|
1, 2, 3, 5, 7.5, 10, 20, 30, 50, 75, 100
|
Proof Load
|
150% of Rated Load
|
Ultimate Breaking Load
|
> 300% of Rated Load
|
Output
|
1.5 mV/V at Rated Load (±10%)
|
Accuracy
|
< ±0.20% of Rated Load
|
Non-Repeatability
|
< ±0.10% of Rated Load
|
Excitation Voltage
|
10vdc recommended, 15vdc maximum
|
Bridge Resistance
|
350Ω, (700Ω for ranges above 30tonne)
|
Insulation Resistance
|
> 500MΩ @ 500vdc
|
Operating Temperature Range
|
-20 to +70°C
|
Compensated Temperature Range
|
-10 to +50°C
|
Zero Temperature Coefficient
|
< ±0.010% of Rated Load/°C
|
Span Temperature Coefficient
|
< ±0.010% of Rated Load/°C
|
Environmental Protection Level
|
IP66 (IP67 optional)
|
Connection Type
|
Integrated bayonet lock connector, supplied with 5 meter mating cable assembly
|
Wiring Connections
|
Red
|
+ve supply
|
Blue
|
-ve supply
|
Green
|
+ve signal
|
Yellow
|
-ve signal
|
|
Options Available
|
Special ranges and sizes available
Different thread arrangements
Special electrical connections
Submersible versions available
Supply with spherical rod-end bearingsy
|
英国LCMsystems TCA称重传感器技术尺寸
Ranges from 1tonne to 100tonne
Stainless Steel construction.
Environmentally Sealed to IP66 (IP67 and submersible versions can also be offered)
Designed to fit standard metric rod-end bearing sizes.
Special Sizes and ranges available.
Can be supplied with imperial threads & male or male/female end threads.
Can be supplied complete with mating spherical rod-end bearings.
The TCA series load cells are based on the conventional low profile or pancake load cell principle. The internal construction is a shear web design, offering high natural frequency, low deflection and excellent resistance to side and torsion forces.
The TCA is constructed from stainless steel offering excellent corrosion resistance. There is an optional mounting base available, which is required if the load cell is to be used in tension. The mounting base is also constructed from stainless steel.
The standard load cell is supplied with an integral MIL spec. connector and supplied with a mating connector.
The TCA is ideally suited to many testing applications, where high stability and low height are essential requirements.
The TCA can be supplied with any of LCM Systems range of load cell instrumentation, and can be supplied calibrated as a complete ready to go system.
