CDIT-2称重传感器详细信息请点击：英国LCMsystems称重传感器：
产品品牌：英国LCMsystems（LOADCELL）
产品类别：CDIT-2不锈钢薄型压缩轮辐式
产品系列：LCM CDIT-2系列称重传感器
产品型号：CDIT-2-250kg,CDIT-2- 500, CDIT-2-1000, CDIT-2-2500, CDIT-2-5000, CDIT-2-7500kg
CDIT-2-10T, CDIT-2-15T, CDIT-2-20T, CDIT-2-30T, CDIT-2-50T, CDIT-2-75t,CDIT-2-100t
产品描述：该CDIT-2系列称重传感器都被设计为各种测力称重应用的空间是有限的。CDIT-2是由不锈钢构成并具有全焊接结构，在恶劣的环境下提供的耐腐蚀性为使用一个高的水平，该系列传感器可与范围涵盖0-250公斤到0-100t，有许多应用相适应的CDIT-2，包括受限制高度称重应用，一般测力和印刷机校准。
英国LCMsystems CDIT-2称重传感器特点
▲范围250千克到100t
▲不锈钢，全焊接结构
▲高稳定性
▲低高度
▲环境密封IP68
英国LCMsystems CDIT-2称重传感器技术参数
|
Rated Load (FSO)
|
250, 500, 1000, 2500, 5000, 7500kg
10, 15, 20, 30, 50, 75, 100te
|
|
Overload Range
|
150% FSO
|
|
Ultimate Breaking Load
|
> 300% FSO
|
|
Output
|
2mV/V (±0.1%)
|
|
Zero Balance
|
<±1% FSO
|
|
Non-Linearity
|
≤±0.03% FSO
|
|
Non-Repeatability
|
≤±0.01% FSO
|
|
Maximum Transverse Load
|
50% FSO
|
|
Transverse Load Effect (at 10% FSO)
|
<±0.03% FSO
|
|
Excitation Voltage
|
10vdc recommended (18vdc maximum)
|
|
Input Resistance
|
700Ω ±3Ω
|
|
Output Resistance
|
7000Ω ±3Ω
|
|
Insulation Resistance
|
>5GΩ @ 50vdc
|
|
Compensated Temperature Range
|
-10 to +40 °C
|
|
Operating Temperature Range
|
-20 to +70 °C
|
|
Storage Temperature Range
|
-20 to +80 °C
|
|
Zero Temperature Coefficient
|
≤±0.005% FSO/°C
|
|
Span Temperature Coefficient
|
≤±0.003% FSO/°C
|
|
Environmental Protection Level
|
IP68
|
|
Electrical Connection
|
Glanded PVC cable - 3 metres long
|
|
Weight (load cell only)
|
250kg to 10te 1.2kg
15te 2kg
20te to 30te 3.8kg
50te to 100te 9.4kg
|
英国LCMsystems CDIT-2称重传感器技术尺寸
Ranges 250kg to 100te
Stainless Steel, fully welded construction
High Stability
Low Height
Environmentally Sealed to IP68
The CDIT-2 series of Load Cells have been designed for a wide range of force measurement and weighing applications where space is limited.
The CDIT-2 is constructed from stainless steel and has a fully welded construction, offering a high level of corrosion resistance for use in harsh environments.
This range of load cells is available with ranges covering 0-250kg to 0-100te.
There are many applications suited to the CDIT-2, including restricted height weighing applications, general force measurements and press calibration.
